Broadband DSL

ADSL2+ and VDSL2 high-speed data service connectivity for both residential and business customers satisfying network modernization needs for all service providers big and small.

Ultra-fast premium services and the broadest reach, symmetry and coverage

Tellabs T1000 MSAP and DSL broadband

Subscribers demand content on-demand with transparency to network capacity as to how many bytes a video requires or how big a picture file is. The subscriber’s target is to get the content they want, when they want it. This means the data services that can be offered over existing copper cable plant need to accommodate residential and business as well as being well equipped for educational and government high-speed applications.

Tellabs enables high-speed Internet services for residential, business, educational and government applications with a variety of rates, reaches and symmetry to ensure that subscribers’ needs are met. ITU standards-based ADSL2+ and VDSL2 offer high bit rates for premium services and the broadest reach, symmetry and coverage available. The Tellabs Broadband offering provides the capacity required for the service needs of both today and the future. The Tellabs products are designed to support small-to-large deployments, from the Central Office and remote outdoor sites.

Quick Facts

  • Tellabs 1000 supports standards-based ADSL2+ and VDSL2
  • ADSL2+ and VDSL2 are supported with integrated POTS on all circuits
  • Bonding is supported for ultra-fast connectivity and business services
  • Service delivery can be in central offices, cabinets, closets or CEVs
  • In-service upgrades gain capacity and QoS required for all customers
  • The latest Broadcom chipset adds flexibility and longevity

Featured Broadband DSL Content

Highlighted Products for Broadband DSL

Tellabs Flex 12 (Flex12) cabinet (MS2)
Tellabs Flex 12 (Flex12) cabinet (MS2)
Tellabs Flex 12 (Flex12) cabinet (710)
Tellabs Flex 12 (Flex12) cabinet (710)
VDSL2 6+6B Plug-in Card
VDSL2 6+6B Plug-in Card

Industry’s only Broadband DLC converging copper and modern fiber connectivity

Flexible delivery of ADSL2+ and VDSL2 services

Tellabs Broadband enables high-speed Internet services for residential, business, educational and government applications with a variety of rates, reaches and symmetry to ensure that subscribers’ needs are met. ITU standards-based ADSL2+ and VDSL2 offer high bit rates for premium services and the broadest reach, symmetry and coverage available.

VDSL2 solutions

Tellabs VDSL2 (Very High Speed Digital Subscriber Line) products support ITU-T G.993.2 VDSL2 simultaneously with POTS on a single copper pair. The product supports profiles 8a and 17a for wide deployment opportunities and access speeds provided up to 100 Mbps. The Tellabs 1000 MSAP VDSL2 6+6 offers a single solution plug-in for high-speed network access. The VDSL2 6+6B provides deployment and application flexibility. When teamed up with Tellabs 1000 Gigabit Ethernet, it can deliver the highest DSL rates available. It supports standard analog POTS integrated on every pair. Two different VDSL2 profiles can be deployed with simple provisioning options.

VDSL2 8a and 17a profiles

The 8a profile is best for fiber-to-the-node (FTTN) applications. Bit rates are up to 50 Mbps and provide reaches suitable for FTTN topologies while supporting triple play services. If a network operator wants to increase reach or speed, the VDSL2 6+6B supports 2-pair bonding that doubles the bit rates up to 100 Mbps. The second profile is 17a. The 17a uses 17 MHz of bandwidth at much higher frequencies. It can support very high rates, up to 100 Mbps downstream and up to 40 Mbps upstream over a single pair. With the higher frequencies, transmission distance is best for fiber-to-the-curb (FTTC) and fiber-to-the-building/basement/equipment closet (FTTB).

VDSL2 and ADSL2+

If reach is critical, the VDSL2 6+6B card can also be provisioned for ADSL2+. In single pair mode applications, the VDSL2 6+6B card supports G.DMT, ADSL, ADSL2, ADSL2-annex L, ADSL2+, ADSL2+-PTM and VDSL2 8a & 17a. With two pair bonding applications, the card supports ADSL2+, ADSL2+-PTM and VDSL2 8a & 17a. Flexibility of deployment environments, a broad range of capacity for all services and the capability to reach all customers make the Tellabs 1000 VDSL2 6+6B card an ideal choice for using a single product type to support all customers and environments. High-speed access to the Internet drives demand for residential and business services. Tellabs Broadband products provide support for xDSL to flexibly provision voice and data services in the way that best meets the needs of our customers.
